Technical Information
14
T1500 Series Clothes Dryers
3.6 Heat Exchanger (Condenser Models Only)
Note
The heat exchanger should be cleaned at least twice a year.
1. Open the Door. Locate the Heat Exchanger Cover near the
bottom / left of the appliance.
2. Turn the lever so that it is in a vertical position (as shown in
figure 3-1).
Figure 3-1: Opening the cover to the Heat Exchanger
3. Remove the cover.
4. Turn both levers on the heat exchanger so that they are vertical
(as shown in figure 3-2).
Figure 3-2: Positioning the Heater Exchanger Levers
