Technical Information
41
T1500 Series Clothes Dryers
6 Fault Diagnosis
6.1 Service Mode –
T1515, T1520, T1526, T1565C & T1570C
Access
1. Switch Off the appliance.
2. Release all Push-Buttons.
3. Turn the Program Selector Switch to the Finish/Start (12
o’clock) position.
4. Switch the appliance On.
5. Press and release the Low Temperature Button (or Load Size
Button – depending on the model number) 3 times in quick
succession within 10 seconds.
Acknowledgement Indicator
The Drying LED flashes to show the Service Mode is activate.
Navigation
Refer to Table 6-1. Turn the Program Selector Knob to the desired
position, then press START.
To exit the Service Mode, Switch Off the appliance.
Selector Switch Position Function
Finish / Start Buzzer pushButton test
Cotton Extra Dry Heater on
Cottons Normal + Drum drives left (vented models only)
Cottons Normal Buzzer Activated
Cottons Hand Iron Drum drives right (vented models only)
Cottons Hand Iron Condenser Fan
(Condenser models only
Cotton Appliance Iron Condensate Pump
(Condenser models only)
15 minutes Cool Air See Residual Moisture Sensor Test
20 minutes Warm Air See Residual Moisture Sensor Test
Permanent Press Hand Iron LED test (LED’s illuminated)
Permanent Press Normal + Dryer type: Continuous Tone = Vented,
Intermittent Tone = Condenser
Table 6-1: Service Mode Functions (T1515, T1520, T1526, T1565C and T1570C).
