Technical Information
27
T1500 Series Clothes Dryers
5.0 Service and Maintenance
Note
Service and repair work should only be performed by qualified
personnel; in accordance with applicable codes.
Warning
The appliance should be unplugged from the power source before
any service and /or maintenance procedures are performed.
5.1 Lid - Removal
Figure 5-1: Lid Removal and Front Panel Access
Refer to figure 5-1.
1. Remove the screws from the side edges of the lid (Item 1).
2. Lift the lid at the front, slide it towards the rear and lift to remove.
To Next Page
