Pellerin Milnor Corporation 17
Table 11 Torque Values if You Apply LocTite 277 (cont'd.)
Dimension
The Grade of the Bolt
Grade 2 Grade 5 Grade 8 Grade BC
Pound-Feet N-m Pound-Feet N-m Pound-Feet N-m Pound-Feet N-m
1-1/2 x 6 1130 1532 2534 3436 4110 5572 3597 4877
1-1/2 x 12 1271 1723 2852 3867 4624 6269
– –
Stainless Steel Fasteners
BNUUUN02.C06 0000222445 A.3 B.3 1/2/20 2:14 PM Released
Table 12. Torque Values for Stainless Steel Fasteners 5/16-inch and Smaller
Dimension
316 Stainless 18-8 Stainless 18-8 Stainless with Loctite 767
Pound-Inches N-m Pound-Inches N-m Pound-Inches N-m
1/4 x 20 79 9 76 9 45 5
1/4 x 28 100 11 94 11 56 6
5/16 x 18 138 16 132 15 79 9
5/16 x 24 148 17 142 16 85 10
Table 13. Torque Values for Stainless Steel Fasteners Larger Than 5/16-inch
Dimension
316 Stainless 18-8 Stainless 18-8 Stainless with Loctite 767
Pound-Feet N-m Pound-Feet N-m Pound-Feet N-m
3/8 x 16 21 28 20 27 12 16
3/8 x 24 23 31 22 29 13 18
7/16 x 14 33 44 31 42 19 25
7/16 x 20 35 47 33 45 20 27
1/2 x 13 45 61 43 58 26 35
1/2 x 20 47 64 45 61 27 37
9/16 x 12 59 81 57 77 34 46
9/16 x 18 66 89 63 85 38 51
5/8 x 11 97 131 93 125 56
75
5/8 x 18 108 150 104 141 62 84
3/4 x 10 132 179 128 173 77 104
3/4 x 16 130 176 124 168 75 101
7/8 x 9 203 275 194 263 116 158
7/8 x 14 202 273 193 262 116 157
1 x 8 300 406 287 389 172 233
1 x 14 271 367 259 351 156 211
1-1/8 x 7 432 586 413 560 248 336
1-1/8 x 12 408 553 390 529 234 317
1-1/4 x 7 546 740 523 709 314 425
1-1/4 x 12 504 683 480 651 288 390
1-1/2 x 6 930 1261 888 1204 533 722
1-1/2 x 12 732 992 703 953 422 572
