Pellerin Milnor Corporation 85
Table 29. Parts List—Suspension Cylinder Assemblies
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
B SA 16 039 *HYDROCUSHION CYL ASSY-"B" CYLINDER ASSY B
C SA 16 038 *HYDROCUSHION CYL ASSY-"C" CYLINDER ASSY C
D SA 28 091 *HYDROCUSHION CYL ASSY-"D" CYLINDER ASSY D
F SA 36 021 *HYDROCUSHION CYL ASSY-"F" CYLINDER ASSY F
G SA 36 023 *HYDROCUSHION CYL ASSY-"G" CYLINDER ASSY G
H SA 36 047 *HYDROCUSHION CYL ASSY-"H" CYLINDER ASSY H
K SA 29 031K *HYDROCUSHION CYL ASSY-"K" CYLINDER ASSY K
(To identify which cylinder is supplied with your machine,
see BPWVUJ02 which should be located in the manual next
to this document. Once you know which cylinder assembly
you have, “B-K” listed above, identify your parts by referenc-
ing the “Used In” coding.)
Components
ABCDK 1 02 18244 BOLT=HYDCYL 27+7/8LG+KEYWAY
K 1 02 18244A BOLT=HYDCYL 28+7/8LG+KEYWAY
FGH 1 03 06201 BOLT=HYDCYL 41+7/8LG+KEYWAY
all 2 02 18840A UPCAP=HYDROCYL 42+52+60
all 4 5SP0KGFSS NPT PLUG 1/2 SOSOLID GALSTL
BC
5 X2 15356 PISTON=HYDROCYL 6"- 6 NOTCH
DFGHK
5 X2 18228 PISTON=HYDROCYL 6"- 3 NOTCH
all 6 5SP0GHFHKM NPT PLUG 3/8"-HEXCSMAGNETIC ZN
FG 7A 03 06139 SPRING=IN HYDRO CYL 331LB/IN FULL SPRING (PURPLE)
G 7B 03 06139A SPRING=IN HYDRO CYL PLUS 1/2 SPRING “G” ONLY
(PURPLE)
H 7C 03 06338 SPRING INNER-GOLD 14"LONG GOLD
B 8 02 16068 MAIN SPRING 212LB/IN RED RED
C 8 02 16125 MAIN SPRING 300LB/IN BLACK BLACK
D 8 02 19039 MAIN SPRING 480LB/IN GREEN GREEN
FG 8 03 06138 SPRING=OUT HYDROCYL 667LB/IN ORANGE
G 8 03 06138A SPRING=OUT HYDRO CYL ORANGE
H 8 03 06337 SPRING-OUTER-GOLD 14.5"LONG GOLD
K 8 03 09016 MAIN SPRING 1035LB/IN BLUE BLUE
ABCDFG-
K
9 02 18619 BUSHING RETAINER + CAD
H 9 03 06358 BUSHING RETAINER.CAD
all 10 15B237 HXCAPSCR 1-8UNC2AX5.5 SAEGR5 Z
all 11 15G255A SQNUT 1-8UNC2B SAE ZINC GR2
all 12 15U400 LOCKWASHER MEDIUM 1" ZINCPL
all 13 60C159A ORING 5.475ID 1/4CS BN70 #433
all 14 24S040 SEAL URETHNE 1-7/16 2.25 13/32
GH 15 M2 18690 LOWER CAP=HYDROCYL
all 16 02 18839A MACHBUSH HYDRCYL CAP #433-OR
Suspension Cylinder Assemblies
3 Sheets
42031,42044,52038,60044,72044
Frame, Pivots, and Suspension
