Table 20. Parts List—Drive Base Installation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A SA 16 021S DRIVE BASE 4244WE SGL MOTOR 4244WP2 SM
B GBJ25003 JACKXHAFT INSTALL 60SG 1 MOTOR
Components
all 1 W2 16141A DRIVEBASE 4244WE 50/60 SGLMOTO
all 2 02 15605E ACTUATOR=EXCURSION SW 42SG-SIG
all 3 02 16088 SWAY BRACE=MOTOR MOUNT 4244
all 4 X2 15604 CLAMP=MACH MTR MTG HINGEPIN
all 5 02 15652 FORK=MOTOR MOUNT ADJ SCREW
all 6 02 21859A BRAKE TORQUE ARM42 1 MOTOR
all 7 05 20131E MTRPLATE 6044SG 1 MOTOR
all 8 54AF22210 PILLBLK BRG - BALDOR DODGE IMPERIAL 2"
all 9 15D119 HXTAPSCR 1/2-13X4 GR5 ZNC FTL
all 10 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 11 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
all 12 15U490 FLTWASH 1+1/2X17/32X1/4 ZINC
all 13 15K180 HXCAPSCR 1/2-13UNCAX2 GR5 ZINC
all 14 15K151 HXCAPSCR 1/2-13UNC2AX1.25 GR5
all 15 15K173A HXCAPSCR 1/2-13UNC2AX1.75 GR5
all 16 02 19283 NUT=1/2-13UNCX1+1/2SQ SPEC
all 17 15K162 HXCAPSCR 1/2-13UNC2AX1.5 GR5 P
all 18 02 11603C WASHER DBLR=1.5W/CUTOFF SIDE
all 19 15P200 TRDCUT-FHXWASHD 3/8-16X3/4NIK
all 20 02 19023 DRIVE BASE ADJ. SCREW 13.5LG
all 21 15G250 HXNUT 1-8UNC2B SAE ZNC GR2
all 22 17W060 SPHERICALWASHER SET 1" M/F
all 23 15U393 FLTWASH 1" HARD ASTM F436
all 24 15K108 SKCPSC 3/8-16 UNC 3X1 BLK
all 25 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 26 15G216 SQNUT 3/8-16UNC2B SAE ZINC GR2
all 27 15K225 HEXCAPSCR 5/8-11X2+1/2
all 28 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 29 02 11603A WASHER DBLR=2" W/CUTOFF SIDE
all 30 02 19577 ADJ ANGLE MOTOR
all 31 02 11603A WASHER DBLR=2" W/CUTOFF SIDE
all 32 15G238 HXNUT 5/8-11UNC2B SAE ZINC GR2
all 33 02 19383 BEARHOUSE MT PLATE FRONT
all 34 15U314 FLATWASHER(USS STD) 5/8" ZNC P
all 35 15U355A 28GA ADJWASH=BRGHOUS ZINC PL
all 36 54M025 HYDFIT 1/8"-90 ALEMITE 1613-B
all 37 5SCC0CBE NPT COUP 1/8 BRASS 125# 103A-A
all 38 5N0C03AG42 NPT NIP 1/8X3 TBE GALSTL SK40
Drive Base Installation
7 Sheets
4244WP2 SM (Single Motor)
