6 - 8 Operator’s Manual
6 Image Acquisition
Display Format
To set the display format of B mode image and M mode image.
Adjust according to the actual situation and obtain a desired analysis through comparison.
Speed
This function is used to set the scan speed of M mode imaging, and the real-time speed value is
displayed in the image parameter area.
Tint Map
This function provides an imaging process based on color difference rather than gray distinction.
Gray Map
Adjusting grayscale contrast to optimize the image.
Edge Enhance
This function is used to increase image profile, so as to distinguish the image boundary.
Larger edge enhance may lead to noise increase.
Dynamic Range
Adjusts contrast resolution of an image, compresses or expands gray display range. The real-time
dynamic range value will be displayed on the image parameter area on the top of the screen.
M Soften
This feature is used to process the scan lines of M images to reject noise, making the image details
to be clearer.
6.5 Color M Mode (CM)
To know the cardiac motion state, CM is overlaid with flow based on M mode, which is more
sensitive to the instantaneous signal changes. Then, it shows the diagnosis information in detail.
TIP:
Linear probe does not support Color M mode.
6.5.1 CM Image Scanning
Perform the following procedure:
1. To enter CM mode:
– In B+M mode, press <C>.
– In B+Color, press <M>.
2. Adjust the image parameters to obtain optimized images.
6.5.2 CM Image Parameters
In CM mode, parameters that can be adjusted are in accordance with those in B, M and Color
modes; please refer to relevant sections of B, Color and M mode for details.
The ROI size and position determine the size and position of the color flow displayed in the color
M mode image.
