4 - 34 Operator’s Manual
4 Setup
HL7 service setting for Worklist is described as follows:
4.8 Network Preset
4.8.1 Network Settings
Transmission Encryption
After accessing the network, click [VPN Config] to enter the “VPN Config” interface.
Item Description
Device Name After you set the server (s) in DICOM Server Setting screen, the name
(s) will appear in the drop-down list, select the name of the Worklist
server.
Service Name Default is server-HL7Query, and it can be modified.
AE Title Application Entity title.here, it should be consistent with that of the
HL7 server.
Port DICOM communication port, 104 by default.Here, the port should be
consistent with that of the HL7 server port.
Maximum Retries Reserved feature.
Interval Time(s) Reserved feature.
Timeout Refers to the amount of time after which the system will stop trying to
establish a connection to the service.
Listen mode This function enables the ultrasound system to use the listen port for
data receiving.
Listen port Port for ultrasound system to receive data after the listen mode function
is activated. Here, the port should be consistent with that of the HL7
server port.
For details of listen port setting, refer to settings in the server.
