2 System Overview
Operator’s Manual 2 - 13
2.10 Control Panel
Figure 2-4 Control panel configured with trackball
Figure 2-5 Control panel configured with trackpad
No. Name English Name Description
1. TDI TDI mode button Enters TDI mode.
P4 User-defined key Undefined button, set by the user in preset.
2. CW CW mode button Enters CW mode.
iTouch iTouch button • Press to enter iTouch mode.
• Long press to exit iTouch mode.
3. M M mode button Press to enter M mode.
4. PW PW mode button Press to enter PW mode.
5. Measure Measure button Press to enter/exit application measurement.
