F3Ci Service Manual
_______________________________________________________________________________________________________________________
29
• Make sure all connectors are firmly in place and all wires and cables are positioned
so that they will not cause obstruction or get damaged when the two halves of the
main body are fitted together.
• Check the coil socket nut (18mm) is done up tightly.
b. Finish assembling the detector by closing the detector body, as described in Section 3.2 –
Closing the Detector Body
Figure 42
: Connecting Battery Connector
Figure 43: and Coil Socket Nut
Battery Connector
