8 . Installation settings and test run
Select the date with ▲ ▼
buttons, and tap the Set
button.
The selected screen is
displayed.
The selected screen is
displayed.
This can be operated while
cooling is stopped. When the
room temperature is too low
to start the cooling test run,
it operates for 30 minutes by
decreasing the set temperature
to 5°C.
Drain pump can be operated
independently.
⑧
Cooling test run
Cooling test run
Back
Start
When tapping [Start], test run starts
for 30 min. at 5°C in cooling.
Finish-condition of test run is follows.
Passage of 30 min./Stop the IU/Change "Set temp",
"Operation mode" on the
TOP screen.
⑨
Drain pump test run
Drain pump test run
Back
Run Stop
Select the item.
③
Installation date
Installation date
yy
mmdd
BackSet
Set the date.
①
Installation settings menu #1
4
3
7
10
18
②
Installation settings menu #2
21
20
24
Enter the phone number of
the company using up to 13
characters and then tap the
Set
button.
⑥
Enter the Phone No.
Phone No.
Back
Set
Delete
Input the phone No & tap [Set].
Enter the company information.
④
Company information
5
6
Company information
Company
Phone No.
Back
Select the item.
Enter the company name
using up to 26 one-byte
characters and then tap the
Set
button. You can enter
alphanumeric or Cyrillic.
⑤
Enter the Company
Company
Back
Set
Number Alphabet
NextDelete
Input the name & tap [Set].
TOP screen
Menu
⇒
Service setting
⇒
Installation settings
⇒
Service password
The selected screen is
displayed.
⑦
Test run
Test run
Cooling test run
Drain pump test run
Compressor Hz xed operation
Back
Select the item.
8
9
This is operable in case
of connecting duct type IU
equipped with the external static
pressure adjustment function.
Select the external static
pressure and tap the Set
button.
⑪
Static pressure adjustment
Static pressure adjustment
Back
Set
Tap ▲▼ to set the value of Pa.
AUTO
Pa
Static pressure adjustment :
Performs external static pressure
Adjustment for the duct unit.
Zone settings : Set when
performing zone control.
Zone settings reset
: Resets all
zone settings.
⑩
Duct unit settings
11
12
17
Set when performing zone
control.
Set whether or not there is a
common zone.
(Enable: Present, Disable: Not
present)
A common zone is a zone in
which a damper is not installed.
⑫
Zone settings
