127
-
'16 • SCM-T-199
5. TABLE OF INDOOR UNIT COMBINATIONS
●
The combinations of the indoor units is indicated by numbers. They are read as follows.
(Example) SRK20ZMX-S → 20 SRK25ZMX-S → 25
●
The capacity of the indoor units is shown by rooms. If this exceeds the maximum capacity of the outdoor unit, the demand
capacity will be proportionally distributed.
●
If units are to be combined, use the table below to make the proper selection.
・Number of connectable indoor units
SCM40ZS-S ,45ZS-S
SCM50ZS-S
2
2
2
3
MIN
MAX
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B Min.
Standard Max.
1
unit
20 2.0 - 1.5 2.0 2.8 560 590 880 2.9 2.8 2.7
25 2.5 - 1.5 2.5 3.4 560 670 1040 3.3 3.2 3.1
35 3.5 - 1.5 3.5 3.9 560 970 1200 4.8 4.6 4.4
2
units
20 + 20 2.00 2.00 3.0 4.0 5.7 600 840 1750 4.2 4.0 3.8
20 + 25 2.00 2.50 3.0 4.5 5.9 600 1040 2030 5.0 4.8 4.6
20 + 35 1.89 3.31 3.0 5.2 5.9 600 1430 2030 6.7 6.4 6.2
25 + 25 2.50 2.50 3.0 5.0 5.9 600 1280 2030 6.1 5.8 5.6
25 + 35 2.17 3.03 3.0 5.2 5.9 600 1430 2030 6.7 6.4 6.2
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B Min.
Standard Max.
1
unit
20 3.0 - 1.3 3.0 3.7 520 750 1070 3.7 3.5 3.4
25 3.4 - 1.3 3.4 4.2 520 920 1210 4.5 4.3 4.1
35 4.5 - 1.3 4.5 5.0 520 1210 1450 5.9 5.6 5.4
2
units
20 + 20 2.25 2.25 2.0 4.5 6.3 550 900 1700 4.4 4.2 4.0
20 + 25 2.36 2.94 2.0 5.3 6.3 550 1150 1700 5.4 5.2 5.0
20 + 35 2.11 3.69 2.0 5.8 6.3 550 1290 1700 6.0 5.8 5.5
25 + 25 2.90 2.90 2.0 5.8 6.3 550 1290 1700 6.0 5.8 5.5
25 + 35 2.42 3.38 2.0 5.8 6.3 550 1290 1700 6.0 5.8 5.5
<Heating>
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B Min.
Standard Max.
1
unit
20 2.0 - 1.5 2.0 2.7 560 650 880 3.2 3.1 3.0
25 2.5 - 1.5 2.5 3.2 560 830 1040 4.1 4.0 3.8
35 3.5 - 1.5 3.5 3.7 560 1100 1200 5.5 5.2 5.0
2
units
20 + 20 2.00 2.00 3.0 4.0 5.6 600 1050 1750 5.2 5.0 4.8
20 + 25 2.00 2.50 3.0 4.5 5.8 600 1300 2030 6.3 6.0 5.8
20 + 35 1.89 3.31 3.0 5.2 5.8 600 1600 2030 7.5 7.2 6.9
25 + 25 2.50 2.50 3.0 5.0 5.8 600 1420 2030 6.7 6.4 6.2
25 + 35 2.17 3.03 3.0 5.2 5.8 600 1600 2030 7.5 7.2 6.9
(b) Indoor unit SKM＊＊ ZSP-S models only
<Cooling>
(1) Model SCM40ZS-S
(a) Indoor unit SRK
ZMX-S models only
