39
-
'16 • SCM-T-199
Adapted to
RoHS
directive
(4) 4way ceiling cassette type (FDTC)
Model
Item
FDTC25VF
Panel
TC-PSA-25W-E
Power source 1 Phase, 220
−
240V, 50Hz
Operation data Cooling Heating
Nominal capacity (1) kW 2.5 3.4
Sound power level
dB(A)
Cooling : 56
Heating : 56
Sound pressure level
Cooling P-Hi : 38 Hi : 36 Me : 32 Lo : 29
Heating P-Hi : 39 Hi : 38 Me : 33 Lo : 29.5
Exterior dimensions
Height x Width x Depth
mm
Unit 248 × 570 × 570
Panel 35 × 700 × 700
Exterior appearance
(Munsell color)
Plaster white
(6.8Y8.9/0.2) near equivalent
Net weight kg UNIT 15 PANEL 3.5
Heat exchanger Louver fin & inner grooved tubing
Air handling equipment
Fan type & Q'ty
Turbo fan × 1
Motor <Starting method> W 33 < Direct line start >
Air flow (Standard) m
3
/min
Cooling P-Hi : 10 Hi : 9 Me : 8 Lo : 6.5
Heating P-Hi : 10.5 Hi : 9.5 Me : 8.5 Lo : 7
Available
external
static pressure
Pa 0
Outdoor air intake Not possible
Air filter, Q'ty Pocket plastic net × 1 (Washable)
Shock & vibration absorber Rubber sleeve (for fan motor)
Insulation (Noise & heat) Polyurethane form
Remote control Wired : RC-E5, RC-EX1A (option) Wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics
Safety equipment
Overload protection for fan motor
Frost protection thermostat
Installation data
Refrigerant piping size
mm
Liquid line :
φ
6.35 (1/4")
Gas line
:
φ
9.52 (3/8")
Connecting method Flare piping
Drain pump Built-in drain pump
Drain Hose connectable with VP20
Insulation for piping Necessary (both Liquid & Gas lines)
IP number IPX0
Standard accessories Mounting kit, Drain hose
Notes (1) The data are measured at the following conditions.
The pipe length is 7.5m.
Item
Operation
Indoor air temperature Outdoor air temperature
Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
ISO5151-T1
Heating 20˚C
−
7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these values are somewhat higher due to ambient temperature.
(4) The operation data indicate when the air-conditioner is operated at 230V 50Hz.
(5) When wireless remote control is used, fan is 3 speed setting(Hi-Me-Lo) only.
D
RWA000Z234
