Mitsubishi SCM45ZS-S User Manual

-
319
-
'16 • SCM-T-199
DUCT JOINT FOR FDTC
PJZ012D073
Duct joint
1
Screw
6
Insulation 1
(120 × 54)
1
Insulation 2
(40 × 60)
2
●
This product is used by assembling on the spacer (TC-OAS-E)
●
Confirm the following parts are included:
1.Before installation
●
Fix the product on the spacer (TC-OAS-E) as shown below.
●
For the installation method, refer to the installation manual of the spacer.
2.Regarding the use of this product
Duct joint
Screw
Spacer
Lid
10.8 Duct joint (FDTC only)
PJZ012D073

Mitsubishi SCM45ZS-S Specifications
