Mitsubishi SCM45ZS-S User Manual

-
131
-
'16 • SCM-T-199
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
20 2.0 - - 1.8 2.0 2.8 500 550 900 2.7 2.6 2.5
25 2.5 - - 1.8 2.5 3.4 500 720 1070 3.6 3.4 3.3
35 3.5 - - 1.8 3.5 3.9 500 1080 1230 5.4 5.1 4.9
50 5.0 - - 1.8 5.0 5.5 500 1700 2000 8.0 7.6 7.3
2
units
20 + 20 2.00 2.00 - 3.0 4.0 5.7 570 910 1800 4.5 4.3 4.2
20 + 25 1.91 2.39 - 3.0 4.3 5.9 570 1070 1980 5.3 5.1 4.9
20 + 35 1.82 3.18 - 3.0 5.0 6.2 570 1430 2070 6.9 6.6 6.3
20 + 50 1.71 4.29 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
25 + 25 2.35 2.35 - 3.0 4.7 6.2 570 1270 2070 6.2 5.9 5.7
25 + 35 2.21 3.09 - 3.0 5.3 6.5 570 1600 2150 7.6 7.2 6.9
25 + 50 2.00 4.00 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
35 + 35 3.00 3.00 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
35 + 50 2.47 3.53 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
3
units
20 + 20 + 20 1.67 1.67 1.67 3.4 5.0 7.1 690 1050 2150 5.2 5.0 4.8
20 + 20 + 25 1.60 1.60 2.00 3.4 5.2 7.1 690 1160 2150 5.7 5.5 5.2
20 + 20 + 35 1.49 1.49 2.61 3.4 5.6 7.1 690 1330 2150 6.5 6.2 5.9
20 + 25 + 25 1.54 1.93 1.93 3.4 5.4 7.1 690 1260 2150 6.2 5.9 5.6
20 + 25 + 35 1.45 1.81 2.54 3.4 5.8 7.1 690 1430 2150 6.9 6.6 6.3
25 + 25 + 25 1.87 1.87 1.87 3.4 5.6 7.1 690 1330 2150 6.5 6.2 5.9
25 + 25 + 35 1.76 1.76 2.47 3.4 6.0 7.1 690 1490 2150 7.1 6.9 6.5
(3) Model SCM50ZS-S
(a) Indoor unit SRK＊＊ ZMX-S models only
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
20 3.0 - - 1.4 3.0 3.7 480 820 1100 4.1 3.9 3.7
25 3.4 - - 1.4 3.4 4.2 480 980 1240 4.9 4.7 4.5
35 4.5 - - 1.4 4.5 5.0 480 1280 1490 6.3 6.0 5.8
50 5.8 - - 1.4 5.8 6.2 480 1740 2260 8.0 7.6 7.3
2
units
20 + 20 2.95 2.95 - 2.0 5.9 7.3 540 1480 2580 7.1 6.8 6.5
20 + 25 2.67 3.33 - 2.0 6.0 7.3 540 1530 2580 7.3 6.9 6.7
20 + 35 2.29 4.01 - 2.0 6.3 7.3 540 1620 2580 7.6 7.2 6.9
20 + 50 1.89 4.71 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
25 + 25 3.05 3.05 - 2.0 6.1 7.3 540 1560 2580 7.4 7.0 6.8
25 + 35 2.67 3.73 - 2.0 6.4 7.3 540 1650 2580 7.7 7.3 7.0
25 + 50 2.20 4.40 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
35 + 35 3.30 3.30 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
35 + 50 2.72 3.88 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
3
units
20 + 20 + 20 2.00 2.00 2.00 3.0 6.0 7.5 600 1240 2580 6.2 5.9 5.7
20 + 20 + 25 1.91 1.91 2.38 3.0 6.2 7.5 600 1400 2580 6.8 6.5 6.2
20 + 20 + 35 1.76 1.76 3.08 3.0 6.6 7.5 600 1560 2580 7.4 7.0 6.8
20 + 25 + 25 1.83 2.29 2.29 3.0 6.4 7.5 600 1470 2580 7.0 6.7 6.5
20 + 25 + 35 1.70 2.13 2.98 3.0 6.8 7.5 600 1620 2580 7.6 7.2 6.9
25 + 25 + 25 2.20 2.20 2.20 3.0 6.6 7.5 600 1560 2580 7.4 7.0 6.8
25 + 25 + 35 2.06 2.06 2.88 3.0 7.0 7.5 600 1690 2580 7.8 7.5 7.2
<Heating>
(3) Model SCM50ZS-S
(a) Indoor unit SRK
ZMX-S models only
<Cooling>
<Heating>
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
20 2.0 - - 1.8 2.0 2.8 500 550 900 2.7 2.6 2.5
25 2.5 - - 1.8 2.5 3.4 500 720 1070 3.6 3.4 3.3
35 3.5 - - 1.8 3.5 3.9 500 1080 1230 5.4 5.1 4.9
50 5.0 - - 1.8 5.0 5.5 500 1700 2000 8.0 7.6 7.3
2
units
20 + 20 2.00 2.00 - 3.0 4.0 5.7 570 910 1800 4.5 4.3 4.2
20 + 25 1.91 2.39 - 3.0 4.3 5.9 570 1070 1980 5.3 5.1 4.9
20 + 35 1.82 3.18 - 3.0 5.0 6.2 570 1430 2070 6.9 6.6 6.3
20 + 50 1.71 4.29 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
25 + 25 2.35 2.35 - 3.0 4.7 6.2 570 1270 2070 6.2 5.9 5.7
25 + 35 2.21 3.09 - 3.0 5.3 6.5 570 1600 2150 7.6 7.2 6.9
25 + 50 2.00 4.00 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
35 + 35 3.00 3.00 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
35 + 50 2.47 3.53 - 3.0 6.0 6.5 570 1960 2150 9.0 8.6 8.2
3
units
20 + 20 + 20 1.67 1.67 1.67 3.4 5.0 7.1 690 1050 2150 5.2 5.0 4.8
20 + 20 + 25 1.60 1.60 2.00 3.4 5.2 7.1 690 1160 2150 5.7 5.5 5.2
20 + 20 + 35 1.49 1.49 2.61 3.4 5.6 7.1 690 1330 2150 6.5 6.2 5.9
20 + 25 + 25 1.54 1.93 1.93 3.4 5.4 7.1 690 1260 2150 6.2 5.9 5.6
20 + 25 + 35 1.45 1.81 2.54 3.4 5.8 7.1 690 1430 2150 6.9 6.6 6.3
25 + 25 + 25 1.87 1.87 1.87 3.4 5.6 7.1 690 1330 2150 6.5 6.2 5.9
25 + 25 + 35 1.76 1.76 2.47 3.4 6.0 7.1 690 1490 2150 7.1 6.9 6.5
(3) Model SCM50ZS-S
(a) Indoor unit SRK＊＊ ZMX-S models only
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard Max. 220V 230V 240V
A B C Min.
Standard max.
1
unit
20 3.0 - - 1.4 3.0 3.7 480 820 1100 4.1 3.9 3.7
25 3.4 - - 1.4 3.4 4.2 480 980 1240 4.9 4.7 4.5
35 4.5 - - 1.4 4.5 5.0 480 1280 1490 6.3 6.0 5.8
50 5.8 - - 1.4 5.8 6.2 480 1740 2260 8.0 7.6 7.3
2
units
20 + 20 2.95 2.95 - 2.0 5.9 7.3 540 1480 2580 7.1 6.8 6.5
20 + 25 2.67 3.33 - 2.0 6.0 7.3 540 1530 2580 7.3 6.9 6.7
20 + 35 2.29 4.01 - 2.0 6.3 7.3 540 1620 2580 7.6 7.2 6.9
20 + 50 1.89 4.71 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
25 + 25 3.05 3.05 - 2.0 6.1 7.3 540 1560 2580 7.4 7.0 6.8
25 + 35 2.67 3.73 - 2.0 6.4 7.3 540 1650 2580 7.7 7.3 7.0
25 + 50 2.20 4.40 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
35 + 35 3.30 3.30 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
35 + 50 2.72 3.88 - 2.0 6.6 7.3 540 1710 2580 7.9 7.5 7.2
3
units
20 + 20 + 20 2.00 2.00 2.00 3.0 6.0 7.5 600 1240 2580 6.2 5.9 5.7
20 + 20 + 25 1.91 1.91 2.38 3.0 6.2 7.5 600 1400 2580 6.8 6.5 6.2
20 + 20 + 35 1.76 1.76 3.08 3.0 6.6 7.5 600 1560 2580 7.4 7.0 6.8
20 + 25 + 25 1.83 2.29 2.29 3.0 6.4 7.5 600 1470 2580 7.0 6.7 6.5
20 + 25 + 35 1.70 2.13 2.98 3.0 6.8 7.5 600 1620 2580 7.6 7.2 6.9
25 + 25 + 25 2.20 2.20 2.20 3.0 6.6 7.5 600 1560 2580 7.4 7.0 6.8
25 + 25 + 35 2.06 2.06 2.88 3.0 7.0 7.5 600 1690 2580 7.8 7.5 7.2
<Heating>
