42
-
'16 • SCM-T-199
Adapted to
RoHS
directive
Model
Item
FDE50VG
Power source 1 Phase, 220
−
240V, 50Hz
Operation data Cooling Heating
Nominal capacity (1) kW 5.0 5.8
Sound power level
dB(A)
60
Sound pressure level P-Hi : 46 Hi : 39 Me : 36 Lo : 31
Exterior dimensions
Height x Width x Depth
mm 210 × 1,070 × 690
Exterior appearance
(Munsell color)
Plaster white
(6.8Y8.9/0.2) near equivalent
Net weight kg 28
Heat exchanger Louver fin & inner grooved tubing
Air handling equipment
Fan type & Q'ty
Centrifugal fan × 2
Motor <Starting method> W 30 < Direct line start >
Air flow (Standard) m
3
/min P-Hi : 13 Hi : 10 Me : 9 Lo : 7
Available external static pressure
Pa 0
Outdoor air intake Not possible
Air filter, Q'ty Pocket plastic net × 2 (Washable)
Shock & vibration absorber Rubber sleeve(for fan motor)
Remote control Wired : RC-E5, RC-EX1A, RCH-E3 (option) Wireless : RCN-E-E (option)
Room temperature control Thermostat by electronics
Safety equipment
Internal thermostat for fan motor
Frost protection thermostat
Installation data
Refrigerant piping size
mm
Liquid line:
φ
6.35 (1/4")
Gas line:
φ
12.7 (1/2")
Connecting method Flare piping
Drain pump —
Drain Hose connectable with VP20
Insulation for piping Necessary (both Liquid & Gas lines)
IP number IPX0
Standard accessories Mounting kit, Drain hose
Notes (1) The data are measured at the following conditions.
The pipe length is 7.5m.
Item
Operation
Indoor air temperature Outdoor air temperature
Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
ISO5151-T1
Heating 20˚C
−
7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these values are somewhat higher due to ambient temperature.
(4) The operation data indicate when the air-conditioner is operated at 230V 50Hz.
(5) When wireless remote control is used, fan is 3 speed setting(Hi-Me-Lo) only.
(5) Ceiling suspended type (FDE)
C
PFA004Z024
To Next Page
