ASTRO Digital XTS 3000 R (Ruggedized) Model Chart
Notes:
X = Item Included
* = The radio’s model number, FLASHcode, Host code, and DSP code are required when placing an order for the Controller Board.
• The model number and (sometimes) the FLASHcode, can be found on the FCC label on the back of the radio.
• The model number, Host code, DSP code, and (sometimes) the FLASHcode, can be found by putting a Model II or III
radio into the Test Mode.
• The model number, Host code, DSP code, and FLASHcode can be found by using the Smart RIB (RLN1015_) and the
RSS to read a Model I, II, or III radio.
** = The Host code and the DSP code are required when placing an order for the Vocoder Board.
MODEL NUMBER DESCRIPTION
H09KDC9PW5BN Ruggedized VHF 1-5 Watt ASTRO Digital XTS 3000 Model I
H09KDF9PW7BN Ruggedized VHF 1-5 Watt ASTRO Digital XTS 3000 Model II
H09KDH9PW7BN Ruggedized VHF 1-5 Watt ASTRO Digital XTS 3000 Model III
H09RDC9PW5BN Ruggedized UHF Range 1 1-4 Watt ASTRO Digital XTS 3000 Model I
H09RDF9PW7BN Ruggedized UHF Range 1 1-4 Watt ASTRO Digital XTS 3000 Model II
H09RDH9PW7BN Ruggedized UHF Range 1 1-4 Watt ASTRO Digital XTS 3000 Model III
H09SDC9PW5BN Ruggedized UHF Range 2 1-4 Watt ASTRO Digital XTS 3000 Model I
H09SDF9PW7BN Ruggedized UHF Range 2 1-4 Watt ASTRO Digital XTS 3000 Model II
H09SDH9PW7BN Ruggedized UHF Range 2 1-4 Watt ASTRO Digital XTS 3000 Model III
H09UCC9PW5BN Ruggedized 800MHz 3 Watt ASTRO Digital XTS 3000 Model I
H09UCF9PW7BN Ruggedized 800MHz 3 Watt ASTRO Digital XTS 3000 Model II
H09UCH9PW7BN Ruggedized 800MHz 3 Watt ASTRO Digital XTS 3000 Model III
ITEM NUMBER DESCRIPTION
XXXXXXXXXX X X NCN6167_ Board, Controller *
XXX NLD8898_ Board, VHF Transceiver (136-174MHz)
XXX NLE4249_ Board, UHF Range 1 Transceiver (403-470MHz)
XXX NLE4250_ Board, UHF Range 2 Transceiver (450-520MHz)
XXXXXXXXXX X X NTN8250_ Board, Vocoder **
XXXXXXXXXX X X NTN8266_ Belt Clip Kit
XXXXXXXXXX X X NTN8297_ Battery, Nickel-Cadmium (1525mAh)
X X X X NTN8311_ Board, Keypad, Model III
X X X X NTN8493_ Board, Keypad, Model II
X X X X NTN8650_ Kit, Ruggedized Front Cover, Model I
X X X X NTN8651_ Kit, Ruggedized Front Cover, Model II
X X X X NTN8652_ Kit, Ruggedized Front Cover, Model III
X X X NUF6472_ Board, 800MHz Transceiver (806-870MHz)
XXXXXXXXXX X X 0705330Z01 Bracket, Display Flex
XXXXXXXXXX X X 0705368Z01 Bracket, Keypad Flex
XXXXXXXXXX X X 0905585Z03 Assembly, B+ Connector
X X X X 1405874Z01 Insulator, Controller
XXXXXXXXXX X X 1505348Z10 Assembly, Casting
XXXXXXXXXX X X 1505579Z01 Cover, Accessory Connector
XXXXXXXXXX X X 2605342Z01 Shield, Controller Board
XXXXXXXXXX X X 2605343Z01 Shield, RF Board
XXXXXXXXXX X X 2605344Z01 Shield, Vocoder
XXXXXXXXXX X X 2805214Z03 Connector, Compression, 50 Pin
XXXXXXXXXX X X 2805216Z03 Connector, Compression, 20 Pin
XXXXXXXXXX X X 3205082E96 Gasket, Antenna O-Ring
XXXXXXXXXX X X 3205349Z04 Seal, Main
XXXXXXXXXX X X 3205351Z02 Seal, B+
XXXXXXXXXX X X 4205631Z01 Clip, Locking
XX XX XX X X 5105385Y19 Module, LCD Display
X X X X 7505293Z02 Keypad, Model III
XX XX XX X X 7505336Z01 Pad, Display Locator
X X X X 7585696A02 Keypad, Model II
X X X 8505241U03 Antenna, 800MHz
XXXXXX 8505241U05 Antenna, UHF
XXX 8505518V01 Antenna, VHF
