8-10
Removing the control flex without installing the universal
connector cover (5) may compromise the universal
connector seal.
5. Disconnect the controls flex from the universal connector.
6. Disconnect the controls flex and backer from PTT area of the
housing assembly.
7. Referring to the Basic Service Manual (68P81083C85), Chapter 6,
remove the frequency knob, frequency insert, secure lever,
lightpipe, volume knob, volume insert, and o-ring.
8. Using a pair of needlenose pliers, unsnap the left snap of the
controls bracket assembly.
9. Remove the controls bracket assembly.
10. Remove and discard the controls seal.
11. Inspect the housing seal surfaces for debris. Remove any debris.
12. Install a new controls seal.
13. Install a new main seal o-ring around the casting assembly.
14. Reassemble the controls bracket assembly.
15. Referring to the Basic Service Manual (68P81083C85), Chapter 6,
install the frequency knob, new frequency escutcheon, new
frequency insert, secure lever, lightpipe, volume knob, new
volume insert, and o-ring.
16. Reconnect the controls flex to the universal connector and the
PTT area of the housing assembly.
17. Reassemble the housing assembly to the radio.
18. Inspect the main seal for proper seating. Observe carefully to
ensure that the main seal o-ring is not pinched between the
housing and the casting.
Frequency Switch,
Toggle, and On/Off/
Volume Control Switch
1. Referring to the Disassembly/Reassembly Procedures, remove the
housing assembly from the radio.
2. Remove the speaker bracket screw.
3. Remove the speaker bracket.
4. Disconnect the controls flex from the universal connector.
5. Disconnect the controls flex and backer from the PTT area of the
housing assembly.
6. Referring to the Basic Service Manual (68P81083C85), Chapter 6,
remove the frequency knob, frequency insert, secure lever,
lightpipe, volume knob, volume insert, and
o-ring.
7. Using a pair of needle nose pliers, unsnap the left snap of the
controls bracket assembly.
8. Remove the controls bracket assembly.
9. Replace the switch that leaks by following the unsoldering and
replacement instructions contained in the new switchs
instruction sheet.
!
C a u t i o n
