3-6
Figure 3-5 +5V Routing for Vocoder Board
Vocoder Board
+5V Digital
From Controller
Board
+5V Analog
From Controller
Board
32K x 8
SRAM
U401
32K x 8
SRAM
U402
32K x 8
SRAM
U403
256K x 8
FLASH
U404
ADSIC
U406
DSP56001A
U405
MAEPF-25997-O
