National Instruments RMC-8356 User Manual

© National Instruments | 3-3
RMC-8356 User Manual
VGA/DVI Port
A VGA connector and a DVI connector are located next to the LAN connector on the I/O back
panel. Use these connections for VGA and DVI displays. The VGA connector is on top and the
DVI is on the bottom.
Table 3-2. Front Panel USB 2.0 Header Pinout
Pin Signal Name
1 +5 V
2 +5 V
3 USB_PN2
4 USB_PN3
5 USB_PP2
6 USB_PP3
7 Ground
8 Ground
9 Key
10 Ground
Table 3-3. Type A USB 10 (3.0) Pinout
Pin Signal Name
1 VBUS
2 USB_N
3 USB_P
4 Ground
5 SSRX-
6 SSRX+
7 GND
8 SSTX-
9 SSTX+
