© National Instruments | A-1
A
Specifications
This appendix lists the RMC-8356 electrical, mechanical, and environmental specifications.
Electrical
AC Input
Input voltage range 100 VAC to 240 VAC
Operating voltage range 90 VAC to 264 VAC
Input frequency 50 Hz/60 Hz
Operating frequency range 47 Hz to 63 Hz
Input current rating 4.2 A max
Power disconnect
The AC power cable provides main power
disconnect. Depressing the front panel power
switch enables or inhibits the internal power
supply.
Caution Using the RMC-8356 in a manner not described in this document may
impair the protection the RMC-8356 provides.
Mainboard
Socket LGA 1151
Chipset Intel C236 chipset
Memory slots 4 x Dual Channel DDR4 UDIMM,
unbuffered ECC/Non-ECC
PCI Express 1 x PCI Express 3.0 x16 slot
SATA 4 x 3.5 in. Hot-Swappable SATA3 Bays
USB ports 2 x USB 2.0 ports (Rear)
4 x USB 3.0 (2 Rear, 2 Front)
