SECTION4–ENGINEOPERATION

PrimingtheFuelSystem

WARNING

Topreventpersonalinjuryordeath,donotsmoke

andkeepfuelawayfromopenamesandsparks.

CAUTION

Topreventenginedamage,donotaddfueltothe

fuellterheader.thiscancontaminatethefuel.

1.Setparkingbrakeandshifttransmissiontoparkorneutral.

2.Verifywaterdrainvalveonprimaryfuellterhousingis

closedandfuelltercapsareontight.

3.TurnignitionswitchtoONforapproximately60seconds

allowingelectricfuelpumptoprimethefuelsystem.

StartingtheEngine

WARNING

Topreventpersonalinjuryordeath,donotuse

ether,propane,gasoline,orgasoholasstarting

aids.

WARNING

Topreventpersonalinjuryordeath,donotinstall

etherstartequipment,ifanenginehasacold

startingdeviceorothercoldclimatestartingaid.

WARNING

Topreventpersonalinjuryordeath,donotuse

etherstartinguidtostartengine.

Figure26Ignitionswitchpositions.

Page46
