SECTION4–ENGINEOPERATION

Generalguidelinesforcorrectroadoperation

1.Usethelowestgeartogetthevehiclemoving.Thisallows

theenginetomoreeasilymovetheload.

2.Acceleratesmoothlyandevenlytoengine'sratedspeed.

Rapidaccelerationcauseshighfuelconsumption.

3.Topreventlugging,donotallowenginespeedtodropbelow

1,200rpmduringfullthrottle.

4.Whenapproachingahill,pressacceleratorsmoothlytostart

theupgradeatfullpower.Downshifttomaintainmaximum

vehiclespeed.

DOWNHILLOPERATION

CAUTION

Topreventenginedamagewhendrivingdownhill,

donotoperatetheengineabovehighidle.

Protectyourenginewhendrivingdownhillasfollows:

•Preventoverspeedingofenginewhengoingdownlong

andsteepgrades.

•Operatetheengineclosesttohighidleformaximum

retardersystemoperation.

•SeeVehicleOperatorManualforengineretardersystem

operationprocedures.

Page56
