SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES

BELT,AIRINTAKEPIPINGANDCLAMPS

ServiceInterval:15,000miles(24,000km),6months,or550

hours

Figure35Cracksinbeltribs

1.Beltingoodcondition

2.Beltreadyforreplacement

3.Beltribs

4.Cracksinbelt

Inspectconditionofalldrivebelts.Foranyofthefollowing

conditionsinstallanewbelt:

•Excessivewear

•Missingmaterial

•Greaseoroilcontamination

•Overthreecracksperinchinabeltrib

BeltRemoval

1.Attacha1/2inchdrivebreakerbartosquareholeinauto

tensioner.

2.Pullthebreakerbarclockwiseandremovethebeltfrom

theautotensionerpulleyandotherpulleys.

3.Slowlyreleasethebreakerbar;theautotensioner

automaticallyadjusts.

4.Removethebreakerbar.

Page73
