NetComm 4GM3W User Manual

www.netcommwireless.com
NetComm Wireless 4GM3W User Guide
13
Web Based Configuration
Interface
First-time Setup Wizard
Please follow the steps below to configure your 4GM3W Wireless router via the web based configuration wizard.
Open your web browser (e.g. Internet Explorer/Firefox/Safari) and type http://192.168.20.1/ into the address bar at the top of the
window.
At the login screen, type admin in the username and password field, then click the Login button.
Note:
admin
is the default username and password of the router.
Click Yes, let’s get started with the wizard to begin configuring your 4GM3W router.
Step 1
Use the drop down menus to select the country and service provider with which you will be using your router. In the PIN and
Confirm PIN fields, enter the PIN number provided to you by your carrier to unlock the SIM card.
Note: If you are using the BigPond service in Australia, you are required to enter the username and password provided to you by
BigPond to access the service.
Click the Next button to continue.

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
