NetComm 4GM3W User Manual

www.netcommwireless.com
NetComm Wireless 4GM3W User Guide
33
Miscellaneous
A Demilitarized Zone (DMZ) Host is a computer without the protection of firewall. It allows that particular computer to be exposed
to unrestricted 2-way communication to the internet. It is mostly used for Internet games, Video conferencing, Internet telephony
and other special applications.
To enable DMZ, enter the IP address of the computer you want to be live on the internet and click on Enable.
Note: This feature should be used only when necessary as it exposes the selected machine to the internet without
protection.
OPTION
DEFINITION
IP Address of DMZ Host
Enter the IP address of the computer you wish to put in the DMZ.
UPnP Setting
The device also supports UPnP. If the DMZ host operating system supports this function enable it to automatically configure
the required network settings.
Click Save to save the settings or Undo to cancel.

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
