NetComm 4GM3W User Manual

62
NetComm Wireless 4GM3W User Guide
www.netcommwireless.com
Technical Data
The following table lists the hardware specifications of the 4GM3W.
MODEL
4GM3W
Wireless LAN
1x1 Internal WiFi (IEEE 802.11ac)
2x2 Internal WiFi (IEEE802.11b/g/n)
Ethernet WAN/LAN port
1 x WAN/LAN port (10/100/1000Mbps)
Connectivity
1 x USB 2.0, 1 x 10/100/1000Mbps WAN/LAN, WLAN
LED Indicators
Power, Internet
Operating Temperature
Operating temperature: 0-40°C, Humidity 10%-90% non-condensing
Storage temperature: -10-70°C, Humidity: 0%-95% non-condensing
Power Input
DC Input Voltage 5V/2A
Dimensions & Weight
98mm (L) x 68mm (W) x 20.5mm(H), 74 grams
Regulatory Compliance
RCM
Electrical Specifications
It is recommended that the 4GM3W be powered by the supplied 12V DC, 2A power supply. A replacement power supply is
available from the NetComm Wireless Online shop.
Environmental Specifications / Tolerances
The 4GM3W housing enables it to operate over a wide variety of temperatures from 0˚C - 40˚C (operating temperature).

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
