NetComm Wireless 4GM3W User Guide
49
Routing
Routing tables allow you to determine which physical interface address to use for outgoing IP data. If you have more than one
router and subnet, you will need to configure the routing table to allow packets to find the proper routing path and allow different
subnets to communicate with each other.
These settings are used to setup the static and dynamic routing features of the 4GM3W.
Dynamic Routing:
Routing Information Protocol (RIP) will exchange information about different host destinations for working out routes throughout
the network.
Note: Only select RIPv2 if you have a different subnet in your network. Otherwise, please select RIPv1.
Static Routing:
For static routing, you can specify up to 8 routing rules.
You need to enter the destination IP address; subnet mask, gateway, and hop for each routing rule, then enable the rule by
clicking the Enable checkbox.
Click on Save to store your setting or Undo to discard your changes.

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
