NetComm 4GM3W User Manual

52
NetComm Wireless 4GM3W User Guide
www.netcommwireless.com
IPv6
The IPv6 page enables you to configure the settings used for an IPv6 connection (if supported by your Internet Service Provider).
OPTION
DEFINITION
IPv6
Select to enable or disable IPv6 functionality.
IPv6 Connection
Select the type of IPv6 connection to utilise for your service. You can select from:

6 to 4

IPv6 in IPv4 Tunnel
Select the type of connection as required by your Internet Service Provider for their IPv6 service.
DNS Setting
Select whether to automatically obtain DNS Server addresses or use the ones you manually specify.
Primary DNS Address
Enter the Primary DNS Address for the IPv6 connection.
Secondary DNS Address
Enter the Secondary DNS Address for the IPv6 connection.
LAN IPv6 Address The IP Address to use for the IPv6 service connection.
LAN IPv6 Link-Local Address
The current local LAN IPv6 address of the NF5.
Autoconfiguration
Select to enable or disable IPv6 auto configuration (if supported by your Internet Service Provider).
Autoconfiguration Type
Select the appropriate type of auto configuration mode as required by your Internet Service Provider for their IPv6 service.
Router Advertisement Lifetime
Enter the length of time between the router advertising its availability on the IPv6 connection.

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
