NetComm Wireless 4GM3W User Guide
NAS Settings
The NAS Settings page enables you to configure the network area storage (NAS) function of the 4GM3W. This function can be
used to remotely access files stored on an attached USB hard drive. Click on any of the menu items to access the respective
configuration page.
Disk Utility
The Disk Utility function enables you to check any attached USB storage for errors. The 4GM3W will scan the attached storage
and determine if there are any file system errors present. File System errors can prevent you being able to access stored content.
You can also format (erase) any attached storage if needed. Simply click the appropriate button to perform either task.
File Sharing
The File Sharing function enables the 4GM3W to take part in a Windows networking environment. Once configured, the attached
USB Storage can be viewed from Windows by typing:
\\<Configured Name of the 4GM3W>\Storage\
Files can then be dragged and dropped onto the attached USB storage.
Enter the computer name the 4GM3W is to use on the network.
Enter the network workgroup the 4GM3W is to be a member of.
Enter the comment to be displayed when a list of network hosts is shown.
The File Sharing configuration also enables you to enable the built-in FTP server function and the associated settings:
Select to enable or disable the FTP server function.
Enter the network port the FTP server should run on.
FTP Max Connections per IP
Enter the maximum number of concurrent connections which can be used by a particular IP address.
Enter the maximum number of clients which can connect to the FTP concurrently.
Enable Unicode support for connected clients.
To Next Page
