NetComm Wireless 4GM3W User Guide
55
Download Assistant
The Download Assistant enables you to schedule the 4GM3W to perform a download from an Internet host.
You are able to select from two download types:
FTP
HTTP
Each type of download job requires different configuration options.
FTP
OPTION
DEFINITION
Job Name
A name to identify the download job.
URL
The address to download from.
Port
The port required for the FTP server (This would usually be left as 21) .
Save To The location on the 4GM3W to save the downloaded file to.
Login Method
Select the type of authentication required by the FTP server (Selecting anonymous means a username and password are not required) .
Username
The username required to access the FTP server.
Password
The password required to access the FTP server.
Start Time
Select to either schedule a time for the download to begin or start the download immediately.

NetComm 4GM3W Specifications

Operating Environment

operating temperature	0-40°C
operating humidity	10%-90% non-condensing
storage temperature	-10-70°C
storage humidity	0%-95% non-condensing

Power

dc input voltage	5V/2A

Ports & Interfaces

usb 2.0 port	1 x USB 2.0 port
switchable wan/lan port	1 x 10/100/1000 Mbps
wps button	1 x WPS button
reset button	1 x Reset button
3g-wan switch	1 x 3G-WAN switch

Wireless

dual band wi-fi	2.4GHz/5GHz
2.4ghz band	IEEE 802.11n
5ghz band	IEEE 802.11ac
concurrent wi-fi	2.4GHz & 5GHz

Weight and Dimensions

dimension	98mm (L) x 68mm (W) x 20.5mm (H)
