NETGEAR Nighthawk RS400 User Manual

Pinging <IP address > with 32 bytes of data
If the path is working, you see this message:
Reply from < IP address >: bytes=32 time=NN ms TTL=xxx
If the path is not working, you see this message:
Request timed out
If the path is not functioning correctly, one of the following problems might be occurring:
•
Wrong physical connections
For a wired connection, make sure that the numbered LAN port LED is lit for the port
to which you are connected.
Check to see that the appropriate LEDs are lit for your network devices. If your router
and computer are connected to a separate Ethernet switch, make sure that the link
LEDs are lit for the switch ports that are connected to your computer and router.
•
Wrong network configuration
Verify that the Ethernet card driver software and TCP/IP software are both installed
and configured on your computer.
Verify that the IP address for your router and your computer are correct and that the
addresses are on the same subnet.
Test the path from a Windows-based computer to a remote
device
To test the path from a Windows-based computer to a remote device:
1. From the Windows toolbar, click the Start button and select Run.
2. In the Windows Run window, type
ping -n 10 <IP address>
where <IP address> is the IP address of a remote device such as your ISP DNS server.
If the path is functioning correctly, messages display that are similar to those shown
in Test the LAN path to your router on page 178.
3.
If you do not receive replies, check the following:
•
Check to see that IP address of your router is listed as the default gateway for
your computer. If DHCP assigns the IP configuration of your computers, this
information is not visible in your computer Network Control Panel. Verify that the
IP address of the router is listed as the default gateway.
•
Check to see that the network address of your computer (the portion of the IP
address specified by the subnet mask) is different from the network address of
the remote device.
User Manual179Troubleshooting
Nighthawk AC2300 Cybersecurity WiFi Router Model RS400

NETGEAR Nighthawk RS400 Specifications

General

NAT functionality	Double firewall protection (SPI and NAT)
DoS attack prevention	Yes
VPN support	Secure access to your home network away from home
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1625 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Power
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Power source type	DC
Package depth	348 mm
Package width	256 mm
Package height	79 mm
Package weight	1450 g
Number of products included	1 pc(s)
Antennas quantity	3
Cables included	DC, LAN (RJ-45)
Browser supported	Internet Explorer, Microsoft Edge, Google Chrome, Firefox, Safari
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Master (outer) case width	190 mm
Master (outer) case height	298 mm
Master (outer) case length	380 mm
Master (outer) case weight	380 g

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
