Reference Manual for the 108 Mbps Wireless Firewall Router WGT624 v3
Content Filtering 4-9
v3.0, December 2005
To specify a Trusted User, enter that computer’s IP address in the Trusted User box and click
Apply. You may specify one Trusted User, which is a computer that will be exempt from blocking
and logging. Since the Trusted User will be identified by an IP address, you should configure that
computer with a fixed IP address.
Blocking Access to Internet Services
The WGT624 v3 wireless router allows you to block the use of certain Internet services by
computers on your network. This is called services blocking or port filtering. The Block Services
menu is shown below:
Services are functions performed by server computers at the request of client computers. For
example, web servers serve web pages, time servers serve time and date information, and game
hosts serve data about other players’ moves. When a computer on your network sends a request for
service to a server computer on the Internet, the requested service is identified by a service or port
number. This number appears as the destination port number in the transmitted IP packets. For
example, a packet that is sent with destination port number 80 is an HTTP (web server) request.
To enable service blocking, select either Per Schedule or Always, then click Apply. If you want to
block by schedule, be sure that a time period is specified in the Schedule menu.
Note: A particular Web site can be blocked by either Netgear keyword blocking or Home
Network Security parental controls (see “Parental Controls” on page 4-3). A
Netgear trusted IP address will be overridden by Home Network Security parental
controls.
Figure 4-4
