APPENDIX A : LIST OF SUPPORTED PRESETS (LOAD2_48)
Appendix A : List of Supported presets (LOAD2_48)
At the time of printing, the following factory presets are supported by LOAD 2_48 by the
NXAMP. Please refer to the documentation enclosed with the firmware if the one loaded in
your NXAMP is not LOAD 2_48.
Keep in mind that you should hold the A & B buttons down when resetting the NXAMP4x1
Powered TD controller to switch from one family of setups to the other.
LOAD2_48 Setup List
Output patch
Setup Name
CH1 CH2 CH3 CH4
FLAT - NO PROTN.
[2 bridged ch ]
FLAT NO PRTN FLAT NO PRTN FLAT NO PRTN FLAT NO PRTN
ALPHATD B1+B1+M3
Wideband-No Sub
ALPHA B115 Wide ALPHA B115 Wide ALPHA MF ALPHA HF
ALPHATD B1+B1+M3
Crossover w S2
ALPHA B115 Xov ALPHA B115 Xov ALPHA MF ALPHA HF
ALPHATD S2+B1+M3
S2-80Hz
ALPHA S2 80 ALPHA B115 Xov ALPHA MF ALPHA HF
ALPHATD S2+B1+M3
S2-63Hz
ALPHA S2 63 ALPHA B115 Xov ALPHA MF ALPHA HF
ALPHATD B1-WB+M3
(B1-15 Bridged)
ALPHA B115 Wide ALPHA MF ALPHA HF
S2 Cabinets x 4
S2-80Hz
ALPHA S2 80 ALPHA S2 80 ALPHA S2 80 ALPHA S2 80
S2 Cabinets x 4
S2-63Hz
ALPHA S2 63 ALPHA S2 63 ALPHA S2 63 ALPHA S2 63
S2 Bridged x 2
S2-63Hz
ALPHA S2 63 ALPHA S2 63
S2 Bridged x 2
S2-80Hz
ALPHA S2 80 ALPHA S2 80
ALPHAe Stereo
AEM + B1-18
ALPHA B118 Wide ALPHA B118 Wide ALPHA E PASSIVE Xov ALPHA E PASSIVE Xov
ALPHAe Stereo X
AEM + B1-18xover
ALPHA B118 Xov ALPHA B118 Xov ALPHA E PASSIVE Xov ALPHA E PASSIVE Xov
ALPHAe Stereo
(B1-18 Bridged)
ALPHA B118 Wide ALPHA E PASSIVE Xov
ALPHAe Stereo X
(B1-18 Bridged)
ALPHA B118 Xov ALPHA E PASSIVE Xov
ALPHAe Mono
AEM B1-18 S2-80
ALPHA S2 80 ALPHA B118 Xov ALPHA E PASSIVE Xov
ALPHAe Mono
AEM B1-18 S2-63
ALPHA S2 63 ALPHA B118 Xov ALPHA E PASSIVE Xov
ALPHAe ACTIVE 3W
2xB1-18 MF HF
ALPHA B118 Wide ALPHA B118 Wide ALPHA E MF ALPHA E HF
ALPHAe ACTIVE 4W
S2 B1-18 MF HF
ALPHA S2 63 ALPHA B118 Xov ALPHA E MF ALPHA E HF
ALPHAe ACTIVE 3W
(B1-18 Bridged)
ALPHA B118 Wide ALPHA E MF ALPHA E HF
PS15 StereoXover
+ S2 Stereo
ALPHA S2 XOV PS15 ALPHA S2 XOV PS15 PS15 Xov S2 PS15 Xov S2
PS15Xov Bridged
+ S2 Bridged
ALPHA S2 XOV PS15 PS15 Xov S2
PS15 Stereo Wide
+ LS1200 Stereo
LS1200 LS1200 PS15 Wide PS15 Wide
PS15 StereoXover
+ LS1200 Stereo
LS1200 LS1200 PS15 Xov PS15 Xov
PAGE 70 OF 80
