Nikon Z 7 User Manual

396 Technical Notes
Technical Notes
Read this chapter for information on the camera display,
compatible accessories, cleaning and storing the camera, and
device specifications.
Refer to this section for information on the indicators in the
camera display (monitor and viewfinder) and control panel. For
illustrative purposes, the displays are shown with all indicators
lit.
The Monitor: Photo Mode
The following indicators appear in the monitor in photo mode.
The Camera Display and Control Panel
39
40
41
42
43
44
45
46
47
22
2
71
156
16
8
911
10
12 13 145
4
3
17
19
21
18
20
23
25 2429
30 283436
3133
32
353738 2627
1 Shooting mode ..............................68
2 Flexible program indicator..........69
3 User setting mode.........................72
4 AF-area brackets............................54
5 Interval timer indicator ............. 210
“Clock not set” indicator ..............40
6 Flash mode ......................... 105, 352
7 Focus indicator...............................59
8 Release mode........................81, 109
9 Focus point ..............................42, 54
10 Focus mode ..................52, 187, 241

Nikon Z 7 Specifications

General

Camera Type	Mirrorless
Sensor Resolution	45.7 megapixels
Sensor Type	CMOS
Image Processor	EXPEED 6
Lens Mount	Nikon Z mount
ISO Range	64-25600 (expandable to 32-102400)
Continuous Shooting	9 fps
Video Resolution	4K UHD at 30p
Battery	EN-EL15b
Weight	675 g (body only)
Dimensions	134 x 100.5 x 67.5 mm
Weather Sealing	Yes
Sensor Size	35.9 x 23.9 mm
Shutter Speed	1/8000 to 30 seconds
Viewfinder	Electronic, 3.69 million dots
Screen	3.2-inch tilting touchscreen, 2.1 million dots
Autofocus System	493-point phase-detection
Image Stabilization	5-axis in-body stabilization
Storage Media	XQD card slot
Battery Life	Approx. 330 shots
