Nikon Z 7 User Manual

416 Technical Notes
Attaching a Power Connector and AC Adapter
Turn the camera off before attaching an optional power
connector and AC adapter.
1 Ready the camera.
Open the battery-chamber
(q) and power connector
(w) covers.
2 Insert the EP-5B power connector.
Be sure to insert the connector in the
orientation shown, using the
connector to keep the orange battery
latch pressed to one side. The latch
locks the connector in place when the
connector is fully inserted.
3 Close the battery-
chamber cover.
Position the power
connector cable so that it
passes through the power
connector slot and close
the battery-chamber cover.

Nikon Z 7 Specifications

General

Camera Type	Mirrorless
Sensor Resolution	45.7 megapixels
Sensor Type	CMOS
Image Processor	EXPEED 6
Lens Mount	Nikon Z mount
ISO Range	64-25600 (expandable to 32-102400)
Continuous Shooting	9 fps
Video Resolution	4K UHD at 30p
Battery	EN-EL15b
Weight	675 g (body only)
Dimensions	134 x 100.5 x 67.5 mm
Weather Sealing	Yes
Sensor Size	35.9 x 23.9 mm
Shutter Speed	1/8000 to 30 seconds
Viewfinder	Electronic, 3.69 million dots
Screen	3.2-inch tilting touchscreen, 2.1 million dots
Autofocus System	493-point phase-detection
Image Stabilization	5-axis in-body stabilization
Storage Media	XQD card slot
Battery Life	Approx. 330 shots
