17
Sound data
The sound from the AIR unit's external unit can be propagated depending on where it is sited relative to the building and the underlying
surface, as well as on other surrounding objects and surfaces.
Sound effect LWA dB(A) 7/6 ºC - 30/35 ºC = 46 db(A) in accordance with EN14511, EN12102 and EN3743/1
Sound pressure LpA dB(A) calculated in accordance with EN13487:2003:
Q = 2 (free-standing) Q = 4 (against a wall) Q = 8 (in a corner)
Distance in metres 1 2 6 10 21
Location factor 2 38 32 22 18 12
Location factor 4 41 35 26 21 15
Location factor 8 44 38 28 24 18
