Nokia 7368 ISAM CPE User Manual

Configure a A-020W-A
96
7368 ISAM CPE A-020W-A Product Guide
3FE-47511-AAAA-TCZZA Issue: 01
Procedure 41 Diagnose connections
1 Select Maintenance > Diagnostics from the top-level menu in the Ethernet Gateway window,
as shown in Figure 46.
Figure 46 Diagnostics window
2 Choose a WAN connection to diagnose from the drop-down menu.
3 Enter the IP address or domain name.
4 Select the test type: ping, traceroute, or both.
5 Enter the number of ping attempts to perform (1 to 1000); the default is 4.
6 Enter a ping packet length (64 to 1500); the default is 64.
7 Enter the maximum number of trace hops (1 to 255); the default is 30.
8 Click Start Test. Results will be displayed at the bottom of the window.
Release 05.08.01 | June 2018 | Edition 01
