Nokia 7368 ISAM CPE User Manual

Configure a A-020W-A
76
7368 ISAM CPE A-020W-A Product Guide
3FE-47511-AAAA-TCZZA Issue: 01
Procedure 25 IP filter configuration
1 Select Security > IP filter from the top-level menu in the Ethernet Gateway window, as shown
in Figure 30.
Figure 30 IP filter window
Table 28 describes the fields in the IP filter window.
Table 28 IP filter parameters
Field Description
Enable IP Filter Select this check box to enable an IP filter
Mode Choose an IP filter mode from the drop-down menu:
• Drop for upstream
• Drop for downstream
Internal Client Choose an internal client from the drop-down menu:
• Customer setting - uses the IP address input below
• IP - uses the connecting devices' IP to the device
Local IP Address Local IP address
Source Subnet Mask Source subnet mask
Remote IP Address Remote IP address
Destination Subnet Mask Destination subnet mask
Protocol Choose an application protocol or all from the drop-down menu
Release 05.08.01 | June 2018 | Edition 01
