Nokia 7368 ISAM CPE User Manual

7368 ISAM CPE A-020W-A Product Guide Replace a A-020W-A
Issue: 01 3FE-47511-AAAA-TCZZA 39
7.6 Procedure
Use this procedure to replace a A-020W-A CPE.
1 Power down the unit by using the on/off power switch. See Figure 9 for the connections on
the A-020W-A CPE.
Figure 9 A-020W-A connections
2 Disconnect the WAN, Ethernet, and power cables from the A-020W-A CPE; see Figure 9 for
the connector locations on the A-020W-A.
3 Replace the A-020W-A CPE with the new A-020W-A. The device can be placed on any flat
surface, such as a desk or shelf.
4 Connect the Ethernet cables directly to the RJ-45 ports; see Figure 9 for the location of the
RJ-45 ports.
5 Connect the WAN cable directly to the RJ-45 port; see Figure 9 for the location of the RJ-45
WAN port.
ON/OFF
WAN
LAN 2
LAN 1
28230
Release 05.08.01 | June 2018 | Edition 01

Nokia 7368 ISAM CPE Specifications

General

Brand	Nokia
Model	7368 ISAM CPE
Category	Wireless Access Point
Language	English
