7368 ISAM CPE A-020W-A Product Guide Configure a A-020W-A
Issue: 01 3FE-47511-AAAA-TCZZA 41
8 Configure a A-020W-A
8.1 GUI configuration
8.1 GUI configuration
Use the procedures below to use the web-based GUI for the A-020W-A CPE.
The A-020W-A CPE is used as an Ethernet gateway to connect devices in the home
to the Internet. The GUI provides a variety of features for the home network including
routing and firewall capability. By using the GUI, users can configure the right
network connectivity fort all equipment in their home, including personal computers,
set-top boxes, mobile phones, and other consumer electronics devices, to the
Internet.
8.1.1 Login
Use the procedure below to login to the web-based GUI for the A-020W-A CPE.
Procedure 6 Login to web-based GUI
1 Open a web browser and enter the IP address of the A-020W-A CPE in the address bar.
The login window appears.
The default gateway IP address is http://192.168.18.1. You can connect to this IP address
using your web browser after connecting your PC to one of Ethernet ports of the A-020W-A
CPE. The static IP address of your PC must be in the same 192.168.18.x subnet as the
A-020W-A.
2 Enter your username and password in the Log in window, as shown in Figure 10.
The default user name is admin. The default password is a random number, which is included
in the A-020W-A CPE kit.
Release 05.08.01 | June 2018 | Edition 01
