CA-128RS RF tuning cable
Product-specific adapter cable for RF tuning.
•
Table 7 Attenuation values
Band Attenuation Rx
GSM850/900 0.30 dB
GSM1800 0.40 dB
GSM1900 0.40 dB
WCDMA I 0.40 dB
CA-31D USB cable
The CA-31D USB cable is used to connect FPS-21 to a PC. It is included
in the FPS-21 sales package.
CA-35S Power cable
CA-35S is a power cable for connecting, for example, the FPS-21 flash
prommer to the Point-Of-Sales (POS) flash adapter.
RM-509; RM-510; RM-511
Service Devices and Service Concepts
Issue 2 COMPANY CONFIDENTIAL Page 2 –13
Copyright © 2009 Nokia. All rights reserved.
