AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016 8
System Cabinets System Overview
2.4.1 Main Power Supply
The NPS-5CHS or NPS-11CHS power supply provides a total of 5.6 A or 11.7 A to the CPU and
has a built-in charger. During normal operation, the NPS can recharge batteries ranging in capacity
from 7 to 85 amp-hours.
See Section 3.10, “Connecting Power Sources and Outputs”, on page 22 for basic power
information.
2.5 System Cabinets
The CPU and modules are installed in a CAB650, CAB900 or U-Series backbox, holding up to four
rows of equipment plus batteries (up to two 85AH batteries). Backboxes can be ordered with
windowed or solid doors. The doors of the 28U and 40U can be mounted on the left or the right side
of the cabinet. A trim ring option is available for semi-flush mounting.
External measurements for each cabinet backbox are provided in Appendix B, “Cabinet and
Mounting Information”, on page 39. Refer to the CAB650, CAB900, or U-Series documentation for
dimensions and door mounting specifications.
2.6 Compatible Equipment
Compatible Notifier and System Sensor equipment that connects directly to the CPU is listed
below. These are the most common devices at time of publishing; the most complete list of
compatible intelligent SLC loop devices is provided in the SLC Wiring Manual; for conventional
non-addressable equipment see the Device Compatibility Document. Other control panels and their
equipment can also be connected in a network, via Noti•Fire•Net version 5.0 or High-Speed
Noti•Fire•Net; refer to the Noti•Fire•Net Version 5.0 Installation Manual or the High-Speed
Noti•Fire•Net Installation Manual for details. Some products are documented in a separate manual;
see Section 1.2 “Related Documents”.
Notifier Compatible Equipment
Annunciators
ACM-24AT Annunciator (Control)
ACM-48A Annunciator (Control)
ACM-8RA 8-way Relay Output Annunciator
ACM-ZM Zone Mimic Annunciator
AEM-24AT Annunciator (expander)
AEM-48A Annunciator (expander)
AEM-ZM Zone Mimic Annunciator Expansion
ARM Agent Release Module Kit
LCD2-80 LCD Annunciator Kit
LDM-32 Lamp Driver Kit
LDM-E32 Lamp Driver Expander Kit
LDM-R32 Lamp Driver Relay Kit
SCE-8A Smoke Control Annunciator
(Expander)
SCS-8A Smoke Control Annunciator (Control)
SCS-8LA Smoke Control Annunciator (Control)
SGD Fire Brigade Alarm Signal Generating
Device
Network Control Modules
HS-NCM-MF Network Control Module - Multi-mode
optical fibre
HS-NCM-MFSF Network Control Module - Multi-mode/
Single-mode optical fibre
HS-NCM-SF Network Control Module - Single-mode
optical fibre
HS-NCM-W Network Control Module - Wire
HS-NCM-WMF Network Control Module - Wire/Multi-
mode optical fibre
HS-NCM-WSF Network Control Module - Wire/ Single-
mode optical fibre
NCA-2NZ Network Control Annunciator
NCM-F Network Control Module - Fibre
NCM-W Network Control Module - Wire
RPT-W NFN Wire-to-Wire Repeater
RPT-WF NFN Wire-to-MMOF repeater
Gateways
BACNET-GW-3 Bacnet gateway
DVC Digital Voice Command
MODBUS-GW Modbus-GW
NWS-3 NOTI-FIRE-NET WebServer
NFN-GW-AU-EM-3 NFN gateway (Embedded)
OnyxWorks OnyxWorks Workstation with and
without PC gateway
VESDA-HLI-GW VESDA-Net gateway
Detector/Sounder Base
AIBS32 Intelligent Base Sounder with
integrated isolator
B501 Addressable Detector Base
B524IEFT Short Circuit Isolator Base
NFX-BF-IVR Addressable Strobe Base (NFX
Series)
NFX-BS-IV Addressable Sounder Base (NFX
Series)
NFXI-BS-IV Addressable Sounder Base (NFX
Series)
NFX-BSF-IVR Addressable Sounder/Strobe Base
(NFX Series)
NFX-WF-RR Addressable Strobe (NFX Series)
NFX-WSF-RR Addressable Sounder/Strobe (NFX
Series)
NFX-WS-R Addressable Sounder (NFX Series)
