AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016 32
Battery Checks and Maintenance Testing the System
4.2.1 PSI Status
Pressing the PSI STATUS button will display the status of the local power supply. This informa-
tion includes the supply voltage, battery voltage, PSI output voltage, which supply source the panel
is running from (PSI or battery), whether a battery test is in progress and whether or not the battery
test and charger have been disabled.
Figure 4.2 PSI Status Screen
PSI STATUS
PSU VOLTAGE: 27.3V
BATTERY VOLTAGE: 24.2V
PSI CONTROL STATUS:
PANEL RUNNING FROM PSI SUPPLY
START BATTERY TEST BACK
