AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016 10
Section 3: Installation
3.1 Preparing for Installation
Choose a location for the fire alarm system that is clean, dry, and vibration-free with moderate
temperature. The area should be readily accessible with sufficient room to easily install and
maintain it. There should be sufficient space for cabinet door(s) to open completely.
Carefully unpack the system and inspect for shipping damage. Count the number of conductors
needed for all devices and find the appropriate knockouts.
Before installing the fire alarm system, read the following:
• Review the installation precautions at the front of this manual.
• Installers should be familiar with the standards and codes specified in Section 1.1 “Agency
Approvals”.
• All wiring must comply with the National and Local codes for fire alarm systems.
• Do not draw wiring into the bottom 25 cm of the cabinet except when using a separate battery
cabinet; this space is for internal battery installation.
• Review installation instructions in Section 3.2 “Installation Checklist”.
3.2 Installation Checklist
The checklist that follows contains references to information included in other manuals; see
Section 1.2 “Related Documents” for document part numbers.
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
MAKE SURE TO INSTALL SYSTEM COMPONENTS IN THE SEQUENCE LISTED BELOW.
FAILURE TO DO SO CAN DAMAGE THE CONTROL PANEL AND OTHER SYSTEM
COMPONENTS.
WARNING: RISK OF IRREPARABLE EQUIPMENT DAMAGE
WEAR A STATIC DISCHARGE STRAP ON WRIST TO PREVENT EQUIPMENT DAMAGE.
Task Refer to:
1. Mount the cabinet backbox to the wall. Appendix B, “Cabinet and Mounting Information”
2. Wire relays Section 3.6 “Form-C Relays on the CPU”
3. Attach & wire other system components
Audio/Voice equipment DVC Digital Voice Command Manual, DAA Digital Audio
Amplifiers Manual, DVC-RPU Manual
Annunciators and other ACS devices Installation document for the specific device (such as ACS
Manual, ACM-8RA Install Sheet, etc.)
Printer or other output device(s) Section 3.11 “Installing Printers”
Network devices Noti•Fire•Net Version 5.0 & Higher Manual/High-Speed
Noti•Fire•Net Manual, and/or Installation document for
specific device(s)
4. Wire the Signalling Line Circuits
(Notification Appliance Circuits and
Initiating Device Circuits)
Section 3.12 “Wiring a Signalling Line Circuit (SLC)” and the
SLC Wiring Manual
5. Calculate the proper battery rating. Main Power Supply Manual
Table 3.1 Installation Checklist (1 of 2)
