ID50 Series Panel - Operating Manual
Operator Actions at Panel
25 997-264-000-8, Issue 8
January 2007
4.9.5 Outputs - User Option
The Test Outputs option, accessed from the Test Menu, tests
the panel’s internal sounder and relay circuits and the Signalling
Line Circuit (SLC) loop outputs. To perform this test:
Test Internal Outputs
1 From the Test Menu, press the ‘
5
’ button on the
numeric keypad to select the Outputs option.
2 Press the ‘
1
’ button on the numeric keypad to display
the Internal Test menu.
3 Use the ‘
2
/
8
’ buttons to select the internal output
required for testing and press the ‘
5
’ button to start
the test. The LCD then displays the following:
4 Check that the output operates. To stop the test, press
the ‘
4
’ button. Press the ‘
4
’ button again to return
to the Test Outputs menu.
Test SLC Outputs
1 From the Outputs menu, press the ‘
2
’ button on the
numeric keypad to display the SLC Output Test menu:
2 Use the ‘
2
/
8
’ buttons to select the output required
for testing and press the ‘
5
’ button to start the test.
The LCD then displays the following:
3 Check that the output operates. To stop the test, press
the ‘
4
’ button. Press the ‘
4
’ button again to return
to the Test Outputs menu.
[Internal Test] B:01 SDR
✓ : Start ↕ : Change Output <:Exit
[U0 Outputs] 1:Internal 2:SLC
3: Loop Power
[Internal Test] B:01 SDR
Output test in progress <:Stop
[SLC Test] M:nn SDR
✓ : Start ↕ : Change Output <:Exit
[SLC Test] M:nn SDR
Output test in progress <:Stop
[U0 Test] 1:LEDs 2:LCD 3:Zones
4:Auto High Test 5:Outputs ↕ : More
[U0 Outputs] 1:Internal 2:SLC
3: Loop Power
