ID50 Series Panel - Operating Manual
Introduction
2997-234-000-8, Issue 8
January 2007
1.2.1 Device Type Abbreviations
Throughout this manual the panel may refer to devices
by an abbreviated name. The following table lists the
device type abbreviation and its description.
Abbreviation Type Description
AUX Plant Warning Input
AVR* Advanced VIEW™ Reference*
AVS* Advanced VIEW™ Sensor*
CTE Monitored (Relay Type) Output (VdS)
CTL Monitored (Relay Type) Output
ESE Extinguishant System Output (VdS)
ESM Extinguishant System
ESO Monitored Extinguishing System Output
EST Extinguishant Monitor System Trigger
ION Ionisation Smoke Detector
IRL Immediate Release Input
MCP† Manual Call Point†
MLT Advanced Multi Sensor
MNS Monitor module (no short-circuit)
MON Fire Alarm Monitor Input
MRL Manual Release Input
OPT Optical/Photo-electric Smoke Detector
OPX Optiplex Multi-sensor
R L E Unmonitored (Relay Type) or O/C Outputs (VdS)
RLY Unmonitored (Relay Type) or O/C Outputs
SDR Monitored (Sounder Type) Output
SM4* SMART Multi-criteria Sensor*
TMP Temperature Detector
TxD Monitored Transmission Routing Output
ZMX Conventional Detector Input
Note: Devices marked ‘*’ are supported by the ID60
Panel only. The Device marked ‘†’ is also
available as ‘DKM’ - not used in this application
(provided to be compatible with VdS
requirements).
1.3 Cleaning
The panel case may be cleaned periodically by wiping
with a soft, damp lint-free cloth.
Do not use solvents.
