Ideal Solution for JBOF and JBOD Systems
BlueField-2 I/O Processing Unit (IPU) is a highly integrated and efficient controller, optimized for NVMe storage systems, Network Functions Virtualization
(NFV), Cloud, and Machine Learning workloads. BlueField-2 integrates all the discrete components of a storage system appliance into a single chip,
including Arm core CPUs, PCIe switch, and a network controller, making it the premier solution for building Just-a-Bunch-Of-Flash (JBOF) systems, All-
Flash-Array, and storage appliances for NVMe over Fabrics. With an integrated NVMe-oF offload accelerator, the BF2500 DPU Controller has a superior
performance advantage over existing JBOF systems, significantly reducing storage transaction latency, while increasing IOPs (I/O operations per second).
BlueField-2 DPU Controllers
Part Number MBF2H516B-EEEOT MBF2H516B-EENOT MBF2H515B-HEEOT MBF2H515B-HENOT
Data Rate InfiniBand: SDR/DDR/QDR/FDR/EDR/HDR100
Ethernet:1/10/25/40/50/100 Gb/s
InfiniBand: SDR/DDR/QDR/FDR/EDR/HDR100/HDR
Ethernet:1/10/25/40/50/100/200 Gb/s
Network Connector Type Dual-port QSFP56 Single-port QSFP56
Form Factor PCIe Full Height, Half Length
Dimensions: 168mm x 111mm (6.61in x 4.37in)
Heatsink Height Single Slot
Height: 14.91mm (from PCB surface)
PCIe Support
(
a)
PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s PCIe Gen 4.0 SERDES @ 16.0GT/s
On-board DDR4 Memory Single-channel with 8 DDR4 8 bit + ECC (64bit + 8bit ECC)
16GB @ 3200MT/s
Single-channel with 8 DDR4 8 bit + ECC (64bit + 8bit ECC)
16GB @ 3200MT/s
1GbE OOB Management √ √ √ √
Crypto Enabled Disabled Enabled Disabled
The BlueField BF2500 DPU Controller should be installed only in a JBOF and JBOD Systems as it functions as a PCIe root-complex (RC) initiating
PCIe bus operations. Installing it in a regular host system may damage the card.
