Nvidia BlueField-2 BF2500 User Manual

79
1.
2.
Updating BlueField Controller Card Firmware
The below steps demonstrate how to manually update the firmware if the automatic process fails. The firmware image can be found in the BlueField
Software package.
Copy the firmware image to the BlueField Arm:
scp fw-BlueField-rel--XX_XX_XXXX-MBF1M6X6A-CSNA_Ax.ini.bin \
root@192.168.100.2:/root
[root@localhost ~]# mst start
Starting MST (Mellanox Software Tools) driver set Loading MST PCI module - Success
Loading MST PCI configuration module - Success Create devices
Unloading MST PCI module (unused) - Success [root@localhost ~]# mst status
MST modules:
------------
MST PCI module is not loaded
MST PCI configuration module loaded
MST devices:
------------
/dev/mst/mt41682_pciconf0
- PCI configuration cycles access.
domain:bus:dev.fn=0000:04:00.0 addr.reg=88 data.reg=92
Chip revision is: 00
The output indicates that the device is “/dev/mst/mt41682_pciconf0”. To update the firmware:
flint -d /dev/mst/mt41682_pciconf0 b \
-i /root/ fw-BlueField-rel-XX_XX_XXXX-MBF1M6X6A-CSNA_Ax.ini.bin
When using the mlx and ini files, use the following command instead:
mlxburn -d /dev/mst/mt41682_pciconf0 -fw fw-BlueField.mlx -c bf.ini
The below commands apply to MBF1M616A-CSNAT. The commands vary per OPN.


Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
