Nvidia BlueField-2 BF2500 User Manual

16
Supported Interfaces
Layout and Connector Information
The BF2500 DPU Controller is aFHHLcard. The component height on the top and bottom of the card complies with the PCIe specification. The below
figures show the connector and LED designations.
The below figures are for illustration purposes only and might not reflect the current revision of the BF2500 card.
BF2500 DPU Controller - Component Side
